Lighting Quantities and Fundamentals

To develop efficient lighting projects, understanding the fundamental lighting quantities is essential. These quantities are based on definitions established by standards such as ISO 8995-1 and by organizations like the Illuminating Engineering Society (IES) in the United States and the British Standards Institution (BSI) in the United Kingdom. Below, we explore the key concepts governing light and its application in lighting design.

Light and Wavelength

Light is the portion of radiant energy visible to the human eye, perceived through the stimulation of the retina. The electromagnetic radiation detectable by the human eye spans wavelengths from 380 to 760 nanometers (nm). A nanometer equals one billionth of a meter.

The wavelength (λ) is the distance between corresponding points of consecutive waves, usually peaks, in a graph of space versus amplitude. The product of wavelength and frequency (f) equals the speed of light (c), which is constant at approximately 186,282 miles per second (or 3 × 10⁸ m/s).

Color of Light

The color of light is determined by its wavelength. Violet light has the shortest visible wavelength (380–450 nm), while red light has the longest (640–760 nm). The visible spectrum, illustrated below, shows that yellow light at 555 nm provides the greatest visual sensitivity.

Lighting Quantities

Luminous Intensity (Candela – cd)

Luminous intensity measures the amount of light emitted by a source in a specific direction. It is defined as the luminous intensity, perpendicular to a flat surface of 1/600,000 square meters of a black body at the temperature of platinum’s freezing point, under 1 atmospheric pressure.

This measure is critical for directional lighting, such as spotlights and reflectors, where intensity in a specific direction is prioritized over general lighting.

Luminous Flux (Lumen – lm)

Luminous flux represents the total amount of light emitted by a source in all directions. It is defined as the light flux emitted within a solid angle of one steradian by a source of one candela.

In practice, luminous flux helps determine the “amount” of light produced by a lamp or fixture, regardless of direction. For example, when comparing different lighting technologies, luminous flux (measured in lumens) provides insight into how much light each type of lamp generates.

Illuminance (Lux – lx)

Illuminance, formerly called illuminance, measures the amount of luminous flux incident on a surface. It is calculated by dividing luminous flux (in lumens) by the area of the surface (in square meters). One lux equals the illuminance on a one-square-meter surface receiving one lumen.

This quantity is vital for determining suitable lighting levels for environments such as offices, homes, or public spaces. Different activities require different levels of illuminance; for instance, a reading room requires higher lux levels than a corridor.

Luminance (cd/m² or Nit)

Luminance measures the amount of light emitted or reflected by a surface in a specific direction, expressed in candelas per square meter (cd/m²), or nit. It describes the apparent brightness of a surface to the human eye.

For example, a TV or computer monitor is characterized by luminance, which determines how bright the image appears to the viewer.

Luminous Efficacy (lm/W)

Luminous efficacy is the ratio of luminous flux emitted by a lamp to the electrical power consumed, expressed in lumens per watt (lm/W).

Higher luminous efficacy means more light is produced per watt of energy consumed, which is crucial for energy-efficient lighting designs. LEDs, for instance, offer high luminous efficacy, making them an energy-efficient choice compared to traditional incandescent bulbs.

Light Distribution Curve

The light distribution curve is a diagram illustrating how a fixture’s luminous intensity is distributed in different directions. Typically presented as a polar diagram, it shows intensities as a function of the angle formed with the vertical.

This diagram is essential for optimizing lighting placement and ensuring targeted illumination, such as in streetlights or floodlights.

Practical Applications in Lighting Design

Understanding these quantities is fundamental in lighting design practice, enabling precise calculations and efficient illumination planning. From selecting light fixtures to determining their placement, every decision affects visual comfort and energy consumption.

FAQ – Frequently Asked Questions about Lighting

1. What is wavelength, and how does it affect the color of light?
Wavelength is the distance between corresponding points on consecutive light waves. It determines the color of light, with shorter wavelengths producing violet light and longer wavelengths producing red light.

2. What is the difference between luminous intensity and luminous flux?
Luminous intensity (measured in candela) is the light emitted in a specific direction, while luminous flux (measured in lumens) is the total light emitted in all directions.

3. How is illuminance measured?
Illuminance is measured in lux, representing the luminous flux per square meter on a surface.

4. What is luminous efficacy, and why is it important?
Luminous efficacy (lm/W) is the ratio of light output to energy consumption. It indicates how efficiently a light source converts energy into visible light, essential for energy-saving designs.

5. What is a light distribution curve?
A light distribution curve shows how a fixture’s luminous intensity varies in different directions, aiding in optimal light placement for desired coverage.
